Product Description
Mold is important equipment in industrial manufacture. Graphite become the best material based on its good physical and chemical properties. Continuous Casting Graphite Mold is widely used in metal casting like Steel & Stainless Steel , Nonferrous metal like Copper & Aluminum and Noble metal like Gold, Silver. In a continuous casting process the pouring and solidification goes non-stops with the casted product being continuously withdrawn from the open end of the mold.
Continuous Casting Graphite has different kind.
Horizontal Continuous Casting Mold & Vertical Continuous Casting Mold based on Casting method;
Round bar Mold & Hollow Pipe Mold & Heteromorphism Mold Based on mold shape.
Advantages of graphite mold
1. Excellent thermal and electric conductivity;
2. Good thermal stability and heating resistance;
3. Good lubricity and wear resistance;
4. High machining strength.
The Material of Continuous Casting Mold:
The choice of the right graphite grade is depending on the composition of the alloy which is being casted.
Physical and chemical index:
Item |
Unit |
OZ-1 |
OZ-2 |
|
Max Grain Size |
Dia |
13-15um |
8-10um |
|
Bulk Density |
|
1.85 |
1.90 |
|
Specific Resistance |
µΩm |
8-10 |
11-13 |
|
Bending Strength |
Mpa |
46 |
60 |
|
Compressive Strength |
Mpa |
85 |
135 |
|
Thermal Conductivity |
W/(m .k) |
139 |
85 |
|
C.T.E.(100-600)℃ |
10-6/℃ |
4.7 |
5.85 |
|
Ash Content |
PPM |
500 |
500 |
